(Vente finale) Integrated tube 2' 10W 100-277V 50K white frosted lens
(Vente finale) Integrated tube 2' 10W 100-277V 50K white frosted lens
Out of stock
This product is oversize. Shipping cost and MOQ may be impacted. Final shipping price calculated at checkout.
Couldn't load pickup availability
Description
Description
Technical specifications
Nomenclature
| Series | Dimensions | Lens | Body Colour | Voltage | CCT | Max Power | Options 1 | Options 2 | VER. |
|---|---|---|---|---|---|---|---|---|---|
| SP | 4D | F | W | A | C | 009 | 0 | D | SY |
| Slim Panel | 4" | frost | white | 120V | 3000-4000-5000K | 9W | N/A | dim TRIAC | SY |
| Series | Dimensions | Lens | Body Colour | Voltage |
|---|---|---|---|---|
| SP | 4D | F | W | A |
| Slim Panel | 4" | frost | white | 120V |
| CCT | Max Power | Options 1 | Options 2 | VER. |
|---|---|---|---|---|
| C | 009 | 0 | D | SY |
| 3000-4000-5000K | 9W | N/A | dim TRIAC | SY |
Photometric Specifications
| CCT | 3CCT (3000-4000-5000K) |
|---|---|
| Angle | 180° |
| C.R.I. | 80.0 |
| Efficiency | 90.0 |
| Lumens (DLC) | 750.0 |
| Lumen maintenance L70 | 50,000 hrs |
| Dimmable | Yes |
| Photocell | Yes |
| Sensor | Yes |
| Flicker | Flicker-Free |
| Application tags | Indoor |
| Application tags (2) | Résidentiel, Commercial |
| Application tags (4) | Indoor |
| Application tags (5) | Commercial |
Electrical Specifications
| Voltage | 120V |
|---|---|
| Max real power | 9.0 |
| Power factor | 95.0 |
| T.H.D | 25.0 |
| Frequency | 50/60Hz |
| Surge protection w/ ground | N/A |
| Surge protection w/o ground | N/A |
Certifications & Other
| Electrical | cETL |
|---|---|
| Waterproof | IP44 |
| Resistance | N/A |
| FCC | N/A |
| DLC applicable | No |
| Efficiency | Energy Star |
Mechanical Specifications
| Housing material | Aluminium |
|---|---|
| Housing finish | White |
| Lens material | PMMA |
| Installation | Recessed |
| Cable length | N/A |
| EPA tilt | N/A |
| Operating temperature | -10°C ~ 40°C |
| Storage temperature | -40°C ~ 70°C |
| LED type | SMD2835 |
| LED qty | 48 |
Dimensions
Packaging
| Unit box dimension | Master box dimension | Master qty | Weight | Pallet qty |
|---|---|---|---|---|
| 595.0 cm X 31.0 cm X 33.0 cm234.25" X 12.2" X 12.99" | 58.0 cm X 44.0 cm X 30.0 cm22.83" X 17.32" X 11.81" | 48 | 0.0 kg0.0 lbs | N/A |
