Split Downlight 4" 20-15-10W 120-347V 30-40-50K Silver frost dim 0-10V
Split Downlight 4" 20-15-10W 120-347V 30-40-50K Silver frost dim 0-10V
Available in stock (21)
Couldn't load pickup availability
Description
Description
Technical specifications
Nomenclature
| Series | Dimensions | Lens | Body Colour | Voltage | CCT | Max Power | Options 1 | Options 2 | VER. |
|---|---|---|---|---|---|---|---|---|---|
| DL | 4D | F | S | F | C | 020 | 0 | D | OK |
| Split Downlight | 4" | frost | Silver | 120-347V | 3000-4000-5000K | 20-15-10W | N/A | dim 0-10V | OKT |
| Series | Dimensions | Lens | Body Colour | Voltage |
|---|---|---|---|---|
| DL | 4D | F | S | F |
| Split Downlight | 4" | frost | Silver | 120-347V |
| CCT | Max Power | Options 1 | Options 2 | VER. |
|---|---|---|---|---|
| C | 020 | 0 | D | OK |
| 3000-4000-5000K | 20-15-10W | N/A | dim 0-10V | OKT |
Photometric Specifications
| CCT | 3000K/4000K/5000K |
|---|---|
| Angle | 55° |
| C.R.I. | 80.0 |
| Efficiency | 75.0 |
| Lumens (DLC) | 1500.0 |
| Lumen maintenance L70 | 50,000 hrs |
| Dimmable | Yes |
| Photocell | Yes |
| Sensor | Yes |
| Flicker | Flicker-Free |
| Application tags (4) | Indoor |
| Application tags (5) | Architectural |
Electrical Specifications
| Voltage | 120-347V |
|---|---|
| Max Power | 20.0 |
| Max real power | 20.0 |
| Power factor | 90.0 |
| T.H.D | 20.0 |
| Frequency | 50/60Hz |
| Surge protection w/ ground | 1KV |
| Surge protection w/o ground | 2KV |
Certifications & Other
| Electrical | cUL |
|---|---|
| Resistance | N/A |
| FCC | false |
| DLC applicable | No |
| Efficiency | Energy Star |
Mechanical Specifications
| Housing material | Aluminium |
|---|---|
| Housing finish | Silver |
| Lens material | PMMA |
| Installation | Recessed |
| Cable length | N/A |
| EPA tilt | N/A |
| Operating temperature | -20°C ~ 45°C |
| Storage temperature | -40°C ~ 70°C |
| LED type | SMD 3030 |
| LED qty | 48 |
Dimensions
Packaging
| Unit box dimension | Master box dimension | Master qty | Weight | Pallet qty |
|---|---|---|---|---|
| 11.0 cm X 11.0 cm X 9.0 cm4.33" X 4.33" X 3.54" | 34.5 cm X 23.5 cm X 24.0 cm13.58" X 9.25" X 9.45" | 12 | 0.45 kg0.99 lbs | 78 |
